H-Rail / H-Truck

Based on a machine chassis and mechanisms UROMAC has developed a new concept of dump truck that maximizes efficiency in maintenance operations while significantly reducing the investment needed.

H-TRUCK hydrostatic transmission and 4×4 traction bring smooth driving on track increasing safety when working/driving from the platform. Moreover the articulated chassis can be blocked to prevent swinging working on height.

Features

  • Articulated chassis

The articulated chassis provides high stability on track especially in stretches under renovation or construction.

  • Easy on and off tracking

This reduces transportation times and increase effective working time.

  • Simplicity and robustness

Designed for long lifetime using heavy duty components from first class manufacturers.

  • Off-road performance

Excellent in most exigent terrains (snow, sand, mud) and easy mount on/off track operation with no need of level crossing.

  • Attachments

Choose from a wide range of attachments to perform any railway maintenance operation.

  • Powerful hydraulics

Efficient hydraulic systems powered by LINDE guarantees performance and interface with railway attachments.

  • Low profile tires

Large pneumatic tires are excellent in all kind of terrains and minimize the maintenance cost and the risk of fails.

  • Railway axles system

Equipped with guiding diplor system available for any railway gauge.

Manual track gauge change by the driver.

  • Transportable

H-RAIL can be transported in trucks or conventional platforms due to its compact design. Loading and unloading maneuvers result quick, simple and safe.

Main specifications

  • Engine: Deutz 100HP/120 HP
  • Transmission: Hydrostatic automotive 4×4 permanent
  • Steering: hydraulic
  • speed: 30 km/h.

Options

  • Crane
  • Scissor lift
  • Electric generator
  • Concrete mixer
  • Brush cutter
  • Snow plunge
  • Cargo box
